600V Welding Cable Flexible Copper Wire
Applications： Welding cables, used as power cables from the welding machine to the electrode, feature a high-strength sheath, excellent abrasi ......
Email: jason@xienuoenterprise.com
Online Chat
Product Detail
Applications：
Welding cables, used as power cables from the welding machine to the electrode, feature a high-strength sheath, excellent abrasion and impact resistance, and exceptional flexibility even at low temperatures. The outer sheath is resistant to abrasion, grease, and water, making them suitable for welders.
Standard：
According to customer's technical specifications
Construction：
1.Conductor：Flexible bare copper
2.Insulation：EPR, According to customer needs
3.Outer Sheath：CPE/PCP/EPDM, According to customer needs
Product Parameters
| Size | Cable Data Sheet | Approx. Weight | ||||
| CU Conductor | Insulation | Outer Sheath | Approx. Overall Dia. | |||
| Str. No. | Diameter | Nominal Thickness | Nominal Thickness | |||
| mm2 | No.s | mm | mm | mm | mm | kg/km |
| 6 | 180 | 0.21 | 0.90 | 1.00 | 7.39 | 104.8 |
| 10 | 300 | 0.21 | 1.00 | 1.00 | 8.94 | 157.4 |
| 16 | 480 | 0.21 | 1.00 | 1.00 | 10.19 | 223.2 |
| 25 | 750 | 0.21 | 1.00 | 1.00 | 11.43 | 315.5 |
| 35 | 1000 | 0.21 | 1.00 | 1.00 | 12.78 | 417.8 |
| 50 | 1500 | 0.21 | 1.10 | 1.10 | 14.68 | 580.2 |
| 70 | 2100 | 0.21 | 1.20 | 1.20 | 17.45 | 801.3 |
| 95 | 2900 | 0.21 | 1.30 | 1.30 | 19.58 | 1063.0 |
| 120 | 3700 | 0.21 | 1.40 | 1.40 | 21.68 | 1328.9 |
| 150 | 4500 | 0.21 | 1.50 | 1.50 | 25.83 | 1672.8 |
| 185 | 5700 | 0.21 | 1.60 | 1.60 | 26.50 | 2013.6 |
| 240 | 7300 | 0.21 | 1.70 | 1.70 | 29.89 | 2580.0 |
